First Article Inspection: Definition, Report Template, and Process

First Article Inspection (FAI) is a critical component in the manufacturing process, ensuring that newly produced parts meet the required specifications and standards before mass production begins. This article delves into the definition of FAI, provides a detailed report template, and outlines the essential steps in the FAI process.

Definition of First Article Inspection

First Article Inspection is a quality control process used to verify that the first production part or sample, known as the “first article,” conforms to the design specifications and requirements. This inspection is conducted before the commencement of full-scale production to ensure that the manufacturing process and production equipment are set up correctly. The primary objective of FAI is to identify and rectify any deviations from the design early in the production cycle, thus preventing costly rework or defects in subsequent parts.

What is the Purpose of FAI?

The purpose of FAI is to inspect a sample of the first product produced in a batch to verify that it adheres to the correct specifications and customer requirements. This process helps identify any issues early, ensuring that manufacturing processes are correctly set up and capable of consistently producing parts that meet quality standards.

What Happens If a Parts Passes or Fails the First Article Inspection?

If a component passes the FAI, production resumes, having confirmed that it meets all expectations. However, if a part fails, production halts until the cause of the failure is identified and corrected. Once issues are addressed, a new FAI is conducted to verify if production can restart. This process is crucial in industries such as defense, aerospace, and medical devices, where precision is vital. Specific sectors may have detailed FAI requirements, such as the AS9102 standard, which provides evidence of quality compliance and accountability throughout the supply chain.

What Situations Call for a First Article Inspection?

When starting production of a new part, or when changes are made to an existing part’s design or production process. Full FAIs are required for new parts, new suppliers, or if there has been a production hiatus of three years or more, conducting an FAI is essential to validate the manufacturing process before it resumes. Similarly, any changes in materials, sourcing, manufacturing processes, tools, or production locations necessitate an FAI.

In industries with stringent quality requirements, such as aerospace, defense, and medical devices, an FAI is crucial to verify that all parts meet the exacting standards required for critical applications. An FAI helps to prevent costly production errors and ensures that parts consistently meet quality and performance specifications.

First Article Inspection Report

A First Article Inspection Report (FAIR) is a critical document that confirms a product has been manufactured according to the required specifications. In the aerospace and defense industries, the FAIR must include three specific forms, each serving a distinct purpose:

1. Form One: Part Number Accountability – This form identifies the part being inspected, along with any related sub-assemblies or detail parts.
2. Form Two: Product Accountability – This form outlines all materials, specifications, processes, and functional tests required by the design.
3. Form Three: Characteristic Accountability – This form details each design characteristic of the inspected part, including dimensions, tolerances, and measurements. It also requires a Balloon Drawing, or Bubble Drawing, which supports this form by linking each design characteristic to its corresponding number.

Additional details in the FAIR typically include the part name and number, the name and signature of the inspector, the date of completion, and customer approval. The FAIR ensures that all parts meet design requirements before full production continues.

First Article Inspection Report Template PDF

Importance of the First Article Inspection Report

1. Quality Assurance: Ensures that the first part produced meets all design and quality specifications before full-scale production begins.
2. Documentation: Provides a formal record that can be used for verification, traceability, and accountability throughout the production cycle.
3. Compliance: Demonstrates adherence to industry standards and customer requirements, especially in regulated sectors like aerospace and defense.
4. Problem Resolution: Helps identify and address any issues early in the production process, reducing the risk of defects and rework.
5. Customer Confidence: Assures customers that the manufacturer has validated the production process and the part’s compliance with specifications, fostering trust and satisfaction.

Tools for First Article Inspection

For effective First Article Inspection (FAI), a range of tools and equipment is used to ensure the parts meet the required specifications and standards. These tools help measure, verify, and document the quality and accuracy of the parts being inspected. Here are some commonly used tools for FAI:

Measurement Tools

Vernier and digital calipers measure internal and external dimensions, as well as depths, while micrometers provide highly accurate measurements of thicknesses and diameters. Height gauges are used to measure vertical dimensions and check heights relative to a reference plane. Dial indicators help detect small variations in dimensions or run-out, ensuring that parts meet the desired specifications.

Inspection Equipment

Coordinate Measuring Machines (CMMs) are crucial for assessing the physical geometrical characteristics of parts. CMMs use probes to touch the part’s surface and obtain precise measurements. Optical comparators project magnified images of parts onto a screen, allowing for comparison with design drawings to inspect dimensional accuracy. Surface plates offer a flat and stable reference surface for measuring and checking flatness. Gage blocks provide precise length standards for calibrating measuring instruments and verifying measurements.

Functional Testing Tools

To ensure parts meet functional requirements, torque wrenches are used to verify that fasteners are tightened to specified values. Pressure testers assess the ability of parts to withstand designated pressures, which is vital for hydraulic or pneumatic components. Electrical testing equipment, such as multimeters and oscilloscopes, is used to check the electrical characteristics and functionality of parts with electrical components.

Visual Inspection Tools

Magnifying glasses aid in examining parts for surface defects and anomalies, while borescopes allow for internal inspections of hard-to-reach areas. High-resolution cameras capture detailed images for thorough visual examination and documentation.

Documentation Tools

FAI report templates standardize the documentation of inspection results, including measurements and test outcomes. Data collection software automates the recording and analysis of inspection data, facilitating accurate and efficient reporting. Calibration certificates are essential for verifying that measurement tools and equipment are calibrated correctly, ensuring the accuracy of the inspection results.

Process of First Article Inspection

The First Article Inspection (FAI) process is a crucial quality assurance step that ensures a product meets design specifications before mass production. Here’s an overview of the FAI process:

1. Review of Design Documentation: This initial step involves thoroughly examining design documents, including engineering drawings, CAD models, and specifications. These documents guide the manufacturing process and identify key inspection requirements, such as critical dimensions and surface finish.
2. Manufacturing of the First Article: After reviewing the design, the first article is manufactured. This step includes setting up machines, calibrating equipment, and arranging tools and materials according to the design specifications.
3. In-depth Inspection of the First Article: The manufactured first article undergoes a detailed inspection. This involves checking dimensions, surface finish, and any special requirements outlined in the design. Inspection tools such as Coordinate Measuring Machines (CMMs) are used to ensure the part meets the specifications.
4. Implementing Corrective Actions: If defects or deviations are found during the inspection, corrective actions are taken. This includes analyzing the causes of defects, adjusting manufacturing processes, and making necessary improvements.
5. Verification and Validation: A second article is produced to verify that the corrective actions were effective. This step includes repeating the inspection process to ensure that the defects have been addressed.
6. Approving for Mass Production: Upon successful verification, the product is approved for mass production. This final step confirms that the manufacturing process is capable of consistently producing parts that meet quality standards.

The FAI process ensures that all aspects of production are thoroughly vetted and optimized, leading to high-quality and reliable products.

What are the Types of First Article Inspection?

Each type of First Article Inspection is tailored to address specific aspects of the manufacturing process and ensures that parts meet the necessary quality and design standards before full-scale production.

Type of FAI	Description
Initial First Article Inspection	Conducted on the very first production part to verify that the setup meets all design specifications.
Full FAI	A comprehensive review covering all aspects of the part, used for significant design or process changes.
Partial FAI	Focuses on specific features or changes rather than a complete inspection.
FAI for Tooling	Verifies that new or modified tooling produces parts that meet specifications.
FAI for Production Changes	Ensures that changes to the production process do not affect part quality.
FAI for Material Changes	Validates that new materials meet specifications and do not adversely impact part performance.
FAI for Supplier Changes	Checks that parts from a new or modified supplier conform to design and quality standards.

What are the First Article Inspection Standards for Different Industries?

First Article Inspection (FAI) standards vary across different industries, reflecting the unique requirements and regulations applicable to each sector. Here’s an overview of some key FAI standards across various industries:

Aerospace Industry

AS9102 Standard

The AS9102 standard is a widely recognized FAI standard in the aerospace industry. It specifies the requirements for FAI reports and the procedures for verifying that parts meet design and specification requirements.

Key Elements:

• Part Number and Revision Level: Document the specific part and its revision.
• Drawing and Specification Requirements: Include all design documents and specifications.
• Inspection Results: Detailed documentation of measurements and test results.
• Sign-Offs: Required approvals from inspectors and quality assurance personnel.

Automotive Industry

AIAG FAI (Automotive Industry Action Group)

The AIAG FAI standard is used in the automotive industry to ensure that parts meet design specifications before production. It focuses on verifying that parts are made correctly and meet all quality and performance requirements.

Key Elements:

• Part Submission Warrant (PSW): Provides a summary of the FAI results.
• Design Documentation: Includes drawings, specifications, and process flows.
• Measurement and Test Results: Comprehensive data on part dimensions and performance tests.
• Corrections and Actions: Documentation of any corrections made and their effectiveness.

Defense Industry

MIL-STD-3039

The MIL-STD-3039 standard is used in the defense industry for FAI. It outlines the procedures for verifying that parts and assemblies conform to their specifications and standards.

Key Elements:

• Inspection and Testing Requirements: Detailed requirements for verifying part quality.
• Documentation: Includes inspection reports, test results, and any deviations from specifications.
• Certification: Certification of compliance from quality control personnel.

Medical Device Industry

ISO 13485

ISO 13485 is an international standard for quality management systems in the medical device industry. While not exclusively an FAI standard, it includes requirements related to FAI within the context of quality management.

Key Elements:

• Design and Development Verification: Ensures that the design meets specifications.
• Process Validation: Verifies that manufacturing processes produce consistent and conforming products.
• Documentation: Includes FAI reports as part of the overall quality management documentation.

Electronics Industry

IPC-9002

IPC-9002 is a standard used in the electronics industry for ensuring that electronic assemblies meet design specifications and quality standards.

Key Elements:

• Design Documentation: Specifications and design requirements for electronic components.
• Inspection Procedures: Guidelines for inspecting and testing electronic assemblies.
• Reporting: Detailed documentation of inspection results and compliance.

General Manufacturing

ISO 9001

ISO 9001 is a general quality management standard applicable across various industries. It includes provisions related to FAI as part of the broader quality management system.

Key Elements:

• Quality Management System Requirements: Framework for ensuring product quality.
• Inspection and Testing: Guidelines for performing inspections and tests.
• Documentation: Requirements for documenting inspection results and corrective actions.

Each industry has specific standards tailored to its requirements, but all share the common goal of ensuring that parts and products meet the necessary specifications and quality levels before full-scale production. Understanding and adhering to these standards is crucial for maintaining compliance and ensuring product reliability and safety.

Who Performs a First Article Inspection?

A First Article Inspection (FAI) is typically performed by a quality control or inspection specialist within the manufacturing or engineering team.

1. Quality Control Inspectors
2. Manufacturing Engineers
3. Inspection Technicians
4. Third-Party Inspectors
5. Quality Assurance Managers

What is the Difference Between PPAP and First Article Inspection?

First Article Inspection (FAI) and Production Part Approval Process (PPAP) are both crucial quality control processes used in manufacturing, but they serve different purposes and are used at different stages of production.

Aspect	First Article Inspection (FAI)	Production Part Approval Process (PPAP)
Purpose	Verify that the first part or batch meets design specifications.	Ensure supplier can consistently produce parts that meet customer requirements.
Scope	Focuses on the initial part or batch of parts.	Covers the entire production process and involves multiple submissions.
Documentation	Includes detailed checks against design documents, CAD models, and specifications.	Includes FAI results, process capability studies, control plans, and validation of production equipment.
When Used	Used at the start of a new production run, or when changing suppliers or processes.	Required before regular production to demonstrate consistent quality.
Key Components	Inspection of initial parts against specifications.	Comprehensive evaluation of manufacturing process and ongoing quality assurance.
Industries	Commonly used in various manufacturing sectors.	Primarily used in the automotive and aerospace industries.
Frequency	Performed for the first article or batch.	Performed at the start of production and involves ongoing reviews.
